What Are Fireproof Coatings And What Do They Do?

In an increasingly unpredictable world, the importance of fire safety cannot be overstated. Fire incidents can cause devastating losses, both in terms of property and lives. To mitigate these risks, fireproof coatings have emerged as a crucial innovation. In this article, we will explore the world of fireproof coatings, their benefits, applications, and how they can provide an extra layer of security to safeguard your property.

What Are Fireproof Coatings

Fireproof coatings, also known as intumescent coatings, are specialized substances applied to surfaces to protect them from the damaging effects of fire. When exposed to high temperatures, these coatings expand and form a protective insulating layer, preventing the underlying material from catching fire.

How Do Fireproof Coatings Work

The science behind fireproof coatings is fascinating. They are typically composed of fire-resistant materials like graphite, epoxy resins, and other proprietary compounds. When exposed to extreme heat, these coatings undergo a chemical transformation that results in the formation of a thick, insulating char layer. This char layer acts as a barrier, reducing heat transfer and preventing the spread of flames.

Benefits of Using Fireproof Coatings

• Enhanced Fire Safety

The primary advantage of fireproof coatings is their ability to enhance fire safety significantly. By slowing down the spread of flames and reducing the intensity of heat, they provide valuable time for occupants to evacuate safely and for firefighters to control the blaze.

• Protection for Structural Integrity

In addition to safeguarding lives, fireproof coatings also protect the structural integrity of buildings. They prevent steel structures from weakening and collapsing in the event of a fire, reducing the risk of extensive damage.

• Compliance with Building Codes

Many building codes and regulations require the use of fireproof coatings in specific settings, such as commercial and industrial buildings. Using these coatings ensures compliance with safety standards and legal requirements.

Types of Fireproof Coatings

Fireproof coatings are materials applied to surfaces to make them more resistant to fire and heat. They can be classified into several types based on their composition and intended application.

Some common types of fireproof coating:

• Intumescent Coatings

Intumescent coatings are the most popular type of fireproof coating. When exposed to high temperatures, they expand to form a charred, insulating layer that protects the underlying substrate from heat and flames. These coatings are commonly used on structural steel in buildings.

• Cementitious Coatings

Cementitious fireproof coatings are made from cement, aggregates, and other additives. They are often applied to concrete and masonry surfaces to enhance their fire resistance. These coatings can withstand high temperatures and are commonly used for tunnel linings and fireproofing structural elements.

• Vermiculite Coatings

Vermiculite-based fireproof coatings contain vermiculite, a naturally occurring mineral that expands when heated. This expansion creates an insulating barrier that protects surfaces from fire and heat. Vermiculite coatings are often used in industrial and commercial applications.

• Gypsum Coatings

Gypsum-based fireproof coatings are made from gypsum plaster and other additives. They are commonly used to protect interior surfaces such as walls and ceilings. These coatings can provide fire resistance for a specified period and are often used in building construction.

• Fire-Resistant Paints

Fire-resistant paints are formulated with fire-retardant chemicals that can slow down the spread of flames on surfaces. While they may not provide the same level of fire resistance as intumescent coatings, they are often used in residential and commercial settings for aesthetic reasons.

• Fireproof Sprays

Fireproof sprays are often used for small-scale fire protection or touch-up applications. They are easy to apply and can be used on various surfaces, including wood, metal, and fabric. These sprays create a fire-resistant barrier when they dry.

• Heat-Reflective Coatings

Heat-reflective coatings are designed to reflect heat away from surfaces, reducing the risk of fire and heat damage. They are often used on roofs and other exterior surfaces to help keep buildings cool and reduce the risk of ignition from external heat sources.

• Fireproof Insulation Coatings

These coatings combine fire resistance with insulation properties, providing thermal protection in addition to fire protection. They are commonly used in industrial and commercial settings where both insulation and fire resistance are required.

• Silicone Coatings

Silicone-based fireproof coatings are known for their durability and resistance to high temperatures. They are often used in applications where exposure to extreme heat is a concern, such as in aerospace or automotive industries.

Choosing the Right Fireproof Coating

• Consider the Type of Surface

Selecting the appropriate fireproof coating depends on the surface you intend to protect. Different coatings are designed for steel, wood, concrete, and other materials. Ensure compatibility for optimal results.

• Evaluate Fire Resistance Ratings

Each fireproof coating has a specific fire resistance rating. This rating indicates the duration for which the coating can withstand the effects of fire. Be sure to choose a coating that aligns with your safety requirements.

• Professional Installation

For the best results, always opt for professional installation of fireproof coatings. Trained technicians ensure that the coatings are applied correctly and adhere to safety standards. Fireproof coatings play a vital role in safeguarding lives and property. Their ability to slow down the spread of fire and protect structural integrity makes them an indispensable component of modern construction.

By choosing the right fireproof coating and ensuring proper installation, you can significantly enhance fire safety in both commercial and residential settings.

Article Source

Earthquake-Resistant Building Design

In a world where natural disasters are becoming increasingly frequent and devastating, the importance of earthquake-resistant building design cannot be overstated. These resilient structures not only save lives but also protect valuable assets. This article link into the intricate world of earthquake-resistant building design, exploring the key principles, innovative technologies, and the future of seismic architecture.

Earthquakes are natural that have shaped our planet for millions of years. However, in today’s urbanized world, these geological events pose a significant threat to human lives and property. To mitigate this risk, architects and engineers have been developing innovative earthquake-resistant building design solutions.

Understanding Earthquakes

Before delving into design solutions, it’s essential to grasp the science behind earthquakes. These are caused by the sudden release of energy in the Earth’s crust, resulting in seismic waves that can cause structural damage. Understanding the mechanics of earthquakes is the first step in designing resilient buildings.

Earthquake-prone regions are categorized into seismic zones based on historical seismic activity. Engineers conduct thorough risk assessments to determine the level of earthquake resistance required for structures in these zones. This assessment informs design decisions.

Throughout history, we’ve witnessed the catastrophic consequences of earthquakes on poorly designed structures. Examining past failures and successes in earthquake-resistant building design provides valuable insights into the evolution of this field.

Seismic Load Evaluation: Ensuring Structural Resilience

Seismic load evaluation is a fundamental step in earthquake-resistant building design. It involves assessing the dynamic forces and ground motions that a structure may experience during an earthquake. Understanding these forces is essential for designing buildings and infrastructure capable of withstanding seismic events. Here are some key concepts related to seismic load evaluation:

1. Seismic Hazard Assessment

Seismic hazard assessment involves determining the level of earthquake risk in a particular region. This assessment considers factors such as historical earthquake data, geological conditions, fault lines, and ground motion predictions. It results in the creation of seismic hazard maps, which classify areas into different seismic zones based on the likelihood and intensity of earthquakes.

2. Seismic Design Ground Motion

Once the seismic hazard is assessed, engineers calculate the expected ground motion at a specific location. Ground motion is characterized by parameters such as peak ground acceleration (PGA), spectral acceleration (Sa), and ground motion response spectra. These values provide critical data for seismic load evaluation.

3. Response Spectrum Analysis

Response spectrum analysis is a method used to evaluate how a structure will respond to ground motion at different frequencies. It involves creating a response spectrum curve that represents the building’s response at various vibration frequencies. Engineers use this analysis to design structures with natural frequencies that align with the seismic forces expected in the area.

4. Equivalent Static Analysis

Equivalent static analysis simplifies the dynamic earthquake forces into a static equivalent, making it easier to apply in structural design. It involves estimating the peak ground motion and then applying it as a uniform lateral force on the structure. While this method simplifies calculations, it may not capture the full dynamic behavior of the building.

5. Dynamic Analysis

Dynamic analysis is a more advanced approach that considers the complex behavior of a building during an earthquake. It takes into account factors such as building stiffness, mass distribution, and damping. There are two primary methods of dynamic analysis: time history analysis, which uses recorded earthquake data, and response spectrum analysis, which uses predefined ground motion spectra.

6. Seismic Load Combinations

Seismic load evaluation includes considering various load combinations, including seismic loads, gravity loads, and other environmental factors. These combinations ensure that the structure is designed to withstand not only seismic events but also everyday loads.

In seismic design, structural engineer needs to consider various load combinations to ensure that buildings and structures can withstand the forces generated during an earthquake. These load combinations are typically prescribed by building codes and seismic design standards and are used to assess the structural integrity and safety of a building. The specific load combinations may vary by region and building code, but here are some common load combinations for seismic design:

• Dead Load (DL) + Seismic Load (EL): This combination considers the permanent weight of the structure and the seismic forces acting on it. The seismic load is usually determined using response spectrum analysis or equivalent lateral force procedures.
• Dead Load (DL) + Live Load (LL) + Seismic Load (EL): This combination includes the effects of both the permanent and live loads, along with the seismic forces. Live loads are temporary loads caused by occupants, furniture, equipment, and other variable factors.
• Dead Load (DL) + Snow Load (SL) + Seismic Load (EL): In areas prone to heavy snowfall, this combination accounts for the weight of snow, along with the dead load and seismic forces.
• Dead Load (DL) + Wind Load (WL) + Seismic Load (EL): For regions with high wind loads, this combination considers the effect of wind forces in addition to dead load and seismic forces.
• Dead Load (DL) + Snow Load (SL) + Live Load (LL) + Seismic Load (EL): This combination takes into account the combined effects of dead load, snow load, live load, and seismic forces, which is relevant in regions with cold climates and the possibility of seismic activity.
• Dead Load (DL) + Wind Load (WL) + Live Load (LL) + Seismic Load (EL): This load combination is used in areas susceptible to both strong winds and seismic activity. It considers the simultaneous effects of these loads along with live and dead loads.
• Dead Load (DL) + Roof Live Load (LLr) + Snow Load (SL) + Seismic Load (EL): In regions with sloped roofs, this combination accounts for the roof’s live load, snow load, and seismic forces in addition to the dead load.
• Dead Load (DL) + Wind Load (WL) + Seismic Load (EL) + Foundation Uplift: This combination includes the effects of wind, seismic forces, and potential uplift forces on the foundation, which may occur in areas with expansive soils or high groundwater levels.

It’s important to note that the specific load combinations and their factors may vary based on local building codes and the characteristics of the structure. Engineers must carefully analyze and design structures to ensure their safety and compliance with applicable regulations, including seismic design codes.

7. Seismic Load-Resisting Systems

Structural engineers use various seismic load-resisting systems, such as shear walls, moment frames, braced frames, and base isolators, to dissipate and distribute seismic forces. The choice of system depends on the building’s design, size, and expected seismic loads.

8. Performance-Based Design

Performance-based design is an innovative approach that focuses on the desired performance of a building during an earthquake. Instead of solely meeting code-prescribed minimums, engineers establish specific performance objectives, such as preventing structural collapse or ensuring occupant safety.

9. Seismic Retrofitting

Seismic load evaluation is also crucial for assessing existing structures and implementing retrofitting measures to enhance their earthquake resilience. Engineers evaluate the structure’s capacity to withstand current seismic loads and recommend retrofitting solutions as needed.

Seismic load evaluation is a multifaceted process that requires a deep understanding of earthquake dynamics and structural behavior.

It is the foundation upon which earthquake-resistant building design is built, ensuring that structures can withstand the forces of nature and protect lives and property during seismic events.

As seismic science and engineering continue to advance, seismic load evaluation techniques will evolve to enhance the safety and resilience of our built environment.

Principles of Earthquake-Resistant Design

Strong Foundations

A strong foundation is crucial in withstanding seismic forces. Deep pile foundations and innovative base isolators can enhance a building’s stability during an earthquake.

Flexible Structures

Buildings designed to flex and sway during an earthquake are less likely to suffer damage. Flexible materials and structural systems are integral to this principle.

Damping Systems

Damping systems are a critical component of earthquake-resistant building design, and they play a pivotal role in safeguarding structures during seismic events. These systems are engineered to absorb and dissipate the energy generated by earthquakes, reducing the structural forces imposed on a building. Let’s delve deeper into the various types of damping systems and their significance:

Tuned Mass Dampers (TMDs)

Tuned Mass Dampers are one of the most widely employed damping systems in earthquake-resistant building design. These devices consist of a massive mass (the tuned mass) mounted within the structure.

The key principle behind TMDs is simple yet effective: when the building starts to sway due to seismic forces, the tuned mass moves in the opposite direction, counterbalancing the motion and reducing the overall vibration of the structure.

TMDs are particularly useful in tall skyscrapers, where the swaying motion during an earthquake can be quite pronounced. By implementing TMDs, engineers can minimize both the lateral displacement and the acceleration experienced by the building, ensuring the safety and comfort of occupants.

Viscous Dampers

Viscous dampers operate on the principle of dissipating energy through the flow of viscous fluid. These dampers are strategically placed within the building’s structure, typically at key locations such as the joints and connections. When seismic forces act upon the building, the viscous fluid within the dampers resists the motion, converting the kinetic energy into heat.

One of the advantages of viscous dampers is their adaptability. Engineers can adjust the damping characteristics by altering the properties of the viscous fluid or changing the size of the dampers. This flexibility allows for fine-tuning the damping system to suit the specific requirements of a building’s design and location.

Friction Dampers

Friction dampers, as the name suggests, rely on the frictional resistance between surfaces to dissipate seismic energy. These dampers consist of sliding or rotating plates that are attached to the building’s structure. During an earthquake, the relative motion between these plates generates frictional forces, which in turn dissipate energy.

Friction dampers are known for their simplicity and reliability. They are often used in combination with other damping systems to provide additional protection. Their low maintenance requirements make them an attractive choice for long-term building resilience.

Fluid Viscous Spring Dampers

Fluid viscous spring dampers combine the principles of fluid viscosity and spring action. These dampers consist of a piston moving within a cylinder filled with viscous fluid, connected to a spring. When seismic forces act on the building, the piston moves, compressing the spring and pushing against the viscous fluid. This action absorbs and dissipates energy.

One of the advantages of fluid viscous spring dampers is their ability to provide both stiffness (spring action) and damping (viscous action). This dual functionality allows engineers to achieve a balanced approach to seismic control, enhancing the building’s overall stability. Damping systems are indispensable in earthquake-resistant building design. They significantly enhance a structure’s ability to withstand seismic forces, safeguarding lives and property. The choice of damping system depends on factors such as building height, location, and structural design, with engineers carefully tailoring the system to meet specific requirements.

As technology advances, we can expect even more sophisticated damping solutions to emerge, further enhancing the resilience of our built environment in the face of earthquakes.

Continue reading on this topic here...

Advantages and Disadvantages of Suspension Bridges

Suspension bridges are an important engineering marvel for traversing larger distances over physical barriers such as rivers, valleys, and other bodies of water. Civil engineers are particularly familiar with the advantages and disadvantages of building suspension bridges and the solutions they can provide. Suspension bridges are one of the oldest bridge types in existence. The first suspension bridge was built over 2,000 years ago in China. The use of suspension bridges has continued to grow and they are now used all over the world. Despite their long history, suspension bridges are still constantly evolving. New technologies and materials are being used to improve the design and performance of suspension bridges.

Advantages of Suspension Bridges

One of the advantages of suspension bridges is that they are very strong and durable. The cables that support the bridge deck can be very thick, meaning that the bridge can support a large amount of weight. This makes them ideal for carrying heavy traffic, such as vehicles and trains. Suspension bridges can also span very long distances, up to 2 kilometers. This is much longer than any other type of bridge.

Another advantage of suspension bridges is that they are very flexible. This means that they can withstand high winds and earthquakes. The flexibility of the bridge deck also means that it can absorb the energy of moving traffic, making the ride smoother for vehicles and trains.

Despite the disadvantages, suspension bridges are still a popular choice for engineers. This is because they offer a number of advantages that other bridge types do not. Suspension bridges are very strong, flexible, and durable. They can span long distances and offer a smooth ride for vehicles. If you are looking to build a bridge, a suspension bridge may be the right choice for you.

The main advantage of a suspension bridge is that it needs relatively few intermediate supports, compared with other types of bridges. This allows them to be constructed over deep valleys while still being able to have foundations much closer together than other types of bridges can. While this feature is valuable in many situations, it does make them prone to more significant damage than other types of bridges during times when heavy loads pass over the bridge or if there are strong winds.

Suspension bridges are the perfect choice for long spans and can be designed to be light to limit their dead weight. Suspension bridges rely on the tension and compression of the deck to support its overall weight without external supports. Lightweight suspension bridges can even use chains instead of cables. When a cable is stretched tight, it resists being pulled more than when it is loose.

Suspension bridges have a number of advantages over other types of bridges. They can be built in areas that are difficult to access by building conventional bridges, directly linking separate geographical locations.

They are usually cheaper to build, since they need less concrete (since the weight is spread out over a greater length).

Maintenance costs for suspension bridges are also lower, because the cables and supports do not require painting or sealing like other bridge types. The Golden Gate Bridge in San Francisco, California is an example of a suspension bridge. It was completed in 1937. The two towers supporting the bridge were built using falsework, with each tower consisting of two hollow tubes sunk into the bedrock on either side of the strait. Once construction was complete, the towers were filled with concrete.

Disadvantages of Suspension Bridges

There are also some disadvantages to building suspension bridges. One of the biggest disadvantages is that they are very expensive to build. The cables and supports that are needed to build a suspension bridge can be very costly. Additionally, suspension bridges can take a long time to build. The long construction time can cause disruptions to traffic and local businesses.

The main disadvantage is that they require very large foundations, which can be a problem in areas with unstable ground and poor soil.

The problem with suspension bridges is that they rely on support from cables anchored at each end of the bridge. When you pick up one end of a long piece of string and hold it out in front of you, it will dangle freely because there is no tension applied to it. If you hang something from that piece of string – perhaps a bowling ball – it will weigh down one end more than the other, causing some pulling on the string but overall not much tension.

Article Source

What Is The Gradient Of The Road And Types Of Gradient Of Road

A gradient is a rate at which a road goes up or down along its path. A road’s gradient rises or decreases with the road’s horizontal alignment. It’s the height difference between where you started and where you ended, expressed over the same length of time. Slopes and other undulations on the land’s surface are the norms rather than the exception. Errors may occur if a road is built there. The road’s gradient absorbs these fluctuations in altitude. To build highways, they must be included since they regulate the transitions between straight stretches. They answer problems like uneven terrain, flooding, high construction costs, and public discontent.

Purpose of Gradient of Roads:

Roads are built to connect two or more places, and the best way to build a road’s grade is to follow the land’s shape as closely as possible to avoid having to do a lot of cutting or filling. For example, in hilly areas, the slope of the road is designed and built to match the slope of the land, but efforts are made to meet the desired maximum slope. Because of this, most roads have 5% to 8% steeper grades.

In flat areas, like urban streets or highways, the road slopes are designed and built first to match the existing ground profile and then drain surface water with systems like pipe/gully or kerb drains. It’s important to remember that roads on completely flat land must have a minimum slope of 0.5% to drain properly.

Importance of Gradient of Roads:

• The most important part of building a road is the gradient. Along the length of the road’s alignment, it’s important to ensure the road has the right slope.
• Gradient lets the vehicle move smoothly around the corners.
• The slope also helps water drain off the roads after it rains.
• Gradients are very helpful on roads with sharp turns in flat areas and drainage problems.
• Before deciding on the road’s slope, it’s important to think about how much it will cost to build, how much it will cost to run cars on it, and what kind of problems might happen on the site.

Effects of Gradient of Roads:

• Gradients have a significant impact on the rate at which vehicles travel. Roads with a high concentration of heavy vehicles require special attention to this issue.
• The slower speeds of these large vehicles are typically enforced on uphill grades when visibility is reduced. Thus, vehicle running expenses rise, and road capacity must be decreased.
• Accidents are common in the grades because of the high speeds between large and light vehicles and between the uphill and downhill gradients.

The Factors for Selection of Gradient of Roads:

• Existing topography influences road grade. The planned road profile must be within the maximum gradient range if the existing topography is hilly.
• The road’s classification determines the road’s gradient. Maximum grades of 3% are recommended for high-speed highways, whereas 6% are recommended for all-purpose single-carriageways.
• Existing and projected drainage systems affect the gradient requirement. If the proposed road is designed where drainage attenuation is needed, it should be atop a barrier to allow a big attenuation pond.
• The bridge approach at both ends affects the grade of the approach road at both ends. In most cases, bridge surface water drainage is managed separately from road drainage; however, road and bridge gradients must be coordinated for a smooth transition.

Types of Gradient of Roads:

1. Ruling Gradient:

The ruling gradient, also called the design gradient, is the steepest angle with which the vertical profile of the road can be made. It depends on the terrain, the inclined length, the speed, the vehicle’s pulling power, and whether or not there is a horizontal curve. If the land is flat, it might be possible to make the slopes flat, but if the land is hilly, it could be more cost-effective and sometimes even possible. The designer picks the rule-of-thumb gradient by using a certain speed as the design speed and a standard-sized vehicle for the design.

2. Exceptional Gradient:

The exceptional gradient is the gradient that is steeper than the limiting gradient. This slope is usually only used in special situations where the roads are shorter than usual. Exceptional gradients are steep gradients used in situations that can’t be avoided, like mountainous areas and terrain. But a steep slope has a downside: it uses more fuel and causes more friction losses.

3. Limiting gradient:

This gradient is used when the cost of the building goes up significantly with the standard gradient. On rolling land or land with hills, it may be necessary to use a limiting gradient. But the length of the steepest parts of the road should be limited, and they should be surrounded by straight roads or roads with less steep grades.

4. Floating Gradient:

A “floating gradient” is a slope where a car moving at a constant speed keeps going down at the same speed without the driver applying power or the brakes.

5. Average Gradient:

For any two places along the alignment, the average gradient is calculated by dividing the vertical difference between them by the horizontal separation. The initial paper location or primary survey benefits from knowing the average grade because it approximates the length of the proposed alignment.

6. Minimum Gradient:

When surface drainage is important, the minimum gradient is used. The side drainage will be taken care of by the camber. But the drainage along the side drains needs a slope so water can flow smoothly. So, there is a minimum slope for drainage, which depends on how much rain falls, the type of soil, and other site conditions. A minimum of 1 in 500 may be enough for concrete drains, and 1 in 200 works well for loose soil drains.

Article Source

What Is Asphalt Floor? Its Uses, Preparation And Installation

Asphalt is petroleum liquid with a very high viscosity. In many settings, asphalt flooring is the best solution. Asphalt mastic is created by mixing asphalt and sand in a 2:1 ratio when used as a flooring layer over a concrete subfloor. In place of sand, asphalt can be used to create a marble mosaic. Aside from asphalt, inert chemicals and mineral pigments are used to create asphalt tiles.

What is Asphalt Flooring?

The components of asphalt flooring are asphalt, chrysotile, paint, and glass beads, resulting in a smooth coating. It has a flat profile of around 1/8 to 3/16 inches and is indestructible, flame-resistant, cheap, and simple to shape. This flooring is well-known for its attractive appearance, as well as its anti-slip and soundproof properties, as well as its resistance to water, dirt, grease, acid, and dirtiness.

Asphalt flooring expands when wet, even when minimal maintenance requirements are followed; linoleum, on the other hand, can be installed in a quarter of the time and is resistant to viruses, acids, oils, and animal fats. Its use becomes appropriate for the ground temperature to be below 27 degrees Celsius.

Where is Asphalt Flooring Used?

Asphalt flooring can be seen in various settings, including parking lots, flyovers, footbridges, and verandas. On an existing concrete slab, its installation time is drastically reduced. It’s a smart idea to widen passageways like patios and bridges. As a result of its toughness and longevity, asphalt flooring is widely favored across the globe. The garage, the flyover, the walkway, and the runways are just a few places where asphalt flooring may be useful.

Preparation and Installation of Asphalt Flooring:

Clean the old floor and remove any cement, sand, or other debris before installing it. Massive equipment is required to break up the old asphalt. All debris from demolition must be removed, and the area must be thoroughly cleaned before the installation can begin. Additionally, cut up the smaller trees and grasses. More tanks in the space between buildings are wasteful and may lead to complications.

Make sure the water drains correctly by setting the lean after cleaning. If the concrete is poured properly, it will delay the collapse of your floors. Water can pool at the edge of the floor because of the design.

A well-installed sub-base is crucial since it serves as the flooring’s central support system and provides a stable foundation. The sub-base serves as an ice bridge in cold weather, minimizing fissures created by the time-consuming thawing process.

It is time to proof roll once the sub-base has hardened and been compacted. The stability of the basic pattern, essential for the asphalt and the load, is ensured by proof rolling.

Layer in your folder structure. The smooth zone of the base and the sub-base must be located before you can set your folder base. Finally, install the new asphalt flooring once a binder coating has been applied. When properly assembled, the sand, oil, and microscopic particles that give it its black appearance can be transformed into a soft, brilliant, and endearing floor.

Your new asphalt joints for pavement, highway, and parking space are the last touch because you’ll need to transition between the two configurations seamlessly.

Repairs to Asphalt Flooring:

Mastic asphalt flooring is convenient because it doesn’t have to be completely removed if damage occurs. Identifying the damaged section of an asphalt floor is the first step in repairing the damaged section. As a next step, the asphalt will be pliable again by applying a “hot poultice” around the circumference of the damaged region. The maintenance worker will use a bolster and hammer to break up the asphalt before shoveling it away.

The exposed edge is cleaned for a broken joint, and heating felt or staple tissue is applied. Depending on the desired thickness, the flooring is layered with asphalt in one or two layers.

Then, the asphalt is recreated and reheated to produce a fusion joint with the rest of the mastic asphalt. As a final step, coarse sand is rubbed into the asphalt, allowing the material to cool.

Advantages of Asphalt Flooring:

• Placing the asphalt flooring catalog in a parking lot will result in a sturdy and long-lasting plane, which will be evaluated for its strength and durability.
• Pavement made of asphalt will have bitumen applied to make it even more watertight.
• Particles are less likely to stick to asphalt flooring than concrete because of the material’s structure.
• Asphalt flooring bases can help smooth out imperfections like sharp corners and edges that would otherwise damage your floor.
• With asphalt, materials may be revived and used again because it does not degrade.
• Asphalt walkways on balconies are a terrific choice for a practical and long-lasting floor.
• Healing with asphalt is rational and straightforward; if you administer asphalt, you will need less supervision.

Disadvantages of Asphalt Flooring:

• Asphalt flooring requires more maintenance than concrete since it must be sealed every four to five years with plaster to keep it from cracking. There will be instances when flying isn’t necessary.
• For the best results, heat the material to between 250 and 350 degrees Fahrenheit before applying it to the asphalt floor of the airplane. Then, coat it with sand or other materials for added compression and longer service life.
• Asphalt will deteriorate if you haven’t varied and positioned it properly, and you can repair and level off cracked or uneven surfaces before flooring.
• In the future, asphalt will be made from fuel, which causes harm when the organic compound is removed—reverse asphalt, which can be used to build asphalt concrete with no organic compounds.
• Asphalt flooring cannot be laid without a tracked truck and the right accessories.

Article Source

7 Types of Home Additions and How to Choose One

A home addition adds finished living space to an existing home. Sooner or later, an addition is a universal desire of most homeowners. Even homeowners who claim that their house is big enough may, from time to time, want a bigger kitchen, an extra bedroom, or a larger bathroom. Enter the home addition.

Home additions range from relatively low-cost attic or basement expansions to expensive and expansive full-size conventional additions that require excavation, footings, and additional siding and roofing. Garage conversions are considered additions since so much living area is added at once. An increasingly popular option is a secondary living structure detached from the main house: an ADU or DADU.

1.) Attic/Basement Conversion

Best for: Adding living space without changing the home footprint.

Although technically not an addition—it doesn't expand the actual footprint of your home—converting existing unfinished space in a basement or attic can be one of the most cost-effective ways to add practical living space. And it is one of the few expansion projects that recoup its full investment through added real estate value.

But an attic or basement must meet certain structural qualifications to make it practical to turn them into code-approved living spaces. Ceiling height must be sufficient, and floor and ceiling structures must meet engineering requirements in order to support the structural loads of active living spaces.

A basement must be completely dry, and attics must be amendable to insulation and ventilation requirements mandated by the local building code. Attic conversions are practical only for homes with attics that are framed without roof trusses. Any converted spaces that include sleeping areas must have egress exits, which may mean adding special windows.

Nationally, the cost of finishing a full attic space averages about $40,000; basement finishing costs are usually about half that. But the costs can vary enormously depending on the size of the space and if structural alterations—such as new egress windows—are necessary.

2.) Conventional Full-Size House Addition

Best for: When much living space is required and property around the home is plentiful.

A conventional house addition is a multi-room structure that is built onto the side of a house and is permanently open to the main house. When well designed, a house addition blends into and creates an entirely different house. A house addition can have many types of areas: great room, dining room, family room, bathroom, guest bedroom, or primary bedroom. But it is rare for an addition to include a kitchen unless the addition is intended as an apartment suite.

Major additions have all of the issues and requirements that come with full house construction. They are subject to all of the same building codes and permit requirements, and they normally require extensive excavation, foundation work, and subcontractors who install wiring, plumbing, and HVAC service. When such additions are designed so that they have all the features needed for independent living, they are sometimes known as AADUs (attached accessory dwelling units).

This kind of project is considered a major addition, and nationally, costs an average of about $72,000, but it is easily possible to spend $150,000 or more if the addition is quite spacious or uses upper-end materials.

3.) Room Addition or Bump Out

Best for: Adding a single room to the home.

A room addition or bump out is a single-room structure built onto the side of a house. It is usually meant for a single function, such as a bedroom or bathroom. Sometimes it only expands the size of a single room in the existing house.

A room addition or house bump out is an addition scaled far down. It might be another 50 square feet added to your kitchen so that you can squeeze in a kitchen island. Or, you might cantilever a few more feet out into thin air to turn a cramped dining area into a comfortable place to eat and socialize. Room additions and bump outs often lay down a new roofline, employing a shed style or flat roof.

While these types of additions are less expensive than full-size, conventional additions, they are not cheap. They are still subject to building codes, permits, and inspectors. They require a foundation—an expensive project itself. So, it's not unusual for a room addition to cost upwards of $50,000.

4.) Sunroom Addition

Best for: Adding protected recreational space but not living space.

A sunroom is an addition to the side of the house that is usually a supplemental living area. Sunrooms typically can be closed off from the main part of the house with doors.

Smaller than a full-size addition, sunrooms are most often made of pre-fabricated materials such as aluminum and thermal-resistant glass and assembled on-site. Sometimes, sunrooms are stick-built from lumber, concrete, and other materials used to build the house itself, resulting in a solidly built living area that visually matches the existing house.

Sunrooms are never used as permanent sleeping areas, and kitchens and bathrooms are never installed in sunrooms. Because sunrooms are not, by code, designed to be year-round permanent living structures, certain features are possible that are not possible when building a conventional addition.

For example, sunrooms can be built with oversized glass and other fenestration that is not possible with a conventional addition. Also, sunrooms are not required to have heating or air conditioning.

5.) Garage Conversion

Best for: Adding a sizable space for an affordable investment; in-law suites.

A garage conversion transforms a one- or two-vehicle-attached garage into a living space by adding flooring, replacing the garage door with a solid wall, and installing a ceiling. Usually, garage conversions become living rooms or bedrooms. Sometimes, garage conversions go full ADU (accessory dwelling unit) and become habitable living spaces, with bathrooms and kitchens. Such projects, known as AADUs (attached accessory dwelling units) are often done at the same time a new detached garage is built elsewhere on the property.

Converting a garage into a living space is a very tempting option since the basic structure of walls, foundation, subfloor, and the roof is already present. In addition, a number of the elements needed for living spaces such as electricity and a couple of windows are already in place—or partially so. Some garages already have drywall on the studs, leaving one less task to do.

6.) Tiny House or DADU (Detached Accessory Dwelling Unit)

Best for: Isolating new living space from the home; rental or in-law suites.

Whether you call it a backyard cottage, tiny house, guesthouse, carriage house, granny pod, or granny flat, an ADU or DADU (detached accessory dwelling unit) adds space to the house and property though it's not physically attached to the home. DADUs add more space for families to live together or they can be rented out to help defray mortgage costs.

Because these are detached units with kitchen appliances, bathrooms, and sleeping/living spaces, a DADU must have its own plumbing, wiring, and HVAC service, rather than piggybacking on the utilities of the main house.

Thus, this is one of the most expensive types of addition, averaging at least $100,000. But in communities where zoning allows for such structures, a tiny house/DADU can become a valuable rental space.

7.) Second Story Addition

Best for: Homes that need much more finished living space, yet land is at a premium.

Second-story additions are major improvements to the home that can double the amount of living space, significantly improve the home's resale value, and accomplish all of this without using any land.

A second-story addition is a major undertaking. The average cost of a second-story addition hovers around $175,000, while some second-story projects reach $600,000. Not only that but building a second-story addition is a serious lifestyle shift. Residents need to live elsewhere for months at a time since the construction is so pervasive throughout the home.3

But the rewards more than balance out the costs. Except for partial second-story additions, expect to double the amount of floor space. That 1,500-square-foot home expands to a generous 3,000 square feet. Not a single square foot of property is used, either. All of the work is built on top of the existing structure.

If you intend to hold onto the home for a long time, consider aging-in-place and mobility issues with second-story additions: How will you move between floors? Local zoning is another issue; your architect and contractor can assist with that.

How to Choose a Home Addition

No matter what the scale, creating a new living space in your home is a major project that requires careful planning and a hard look at your budget. Such a project can range from finishing off the unfinished attic, basement, or garage space at a cost of $20,000 or less, to major multi-room additions or a DADU (detached accessory dwelling unit) that can cost $100,000 or more.

While adding living space is a major investment, it can be a very logical approach if the need for more space is pressing and if the family budget allows for it. It is almost always more affordable, not to mention more convenient, to add on to an existing home rather than uproot your family to move to a new, more expensive residence. But give the project careful thought to make sure you are getting precisely what you need.

Will the Number of Residents Change?

A small bump-out may seem logical for today's needs, but what about if your family expands? Or if aging parents need to come live with you? On the other hand, if you are anticipating an empty nest situation in the next few years, rather than a major multi-room addition, a smaller project that adds a luxury bath or home theater might be the better approach.

Will Your Financial Situation Change?

Young families on a budget may want to minimize the cost of their home improvement, but in a few years after careers advance, you may regret not investing in a more significant home addition. On the other hand, if you anticipate retiring in a few years, then now may not be the time to take on HELOC (home equity line of credit), home improvement loan, a second mortgage to pay for that major project.

Will the Home Addition Add to the Home Value?

Thoughtful, well-planned home additions can recoup a large percentage of their costs in added equity when you eventually sell the house. Such increased value is usually realized some years down the road—not immediately; major home additions are usually not a good idea if you plan to sell your home soon.

How Much Is the Funding Costing You?

If you will be borrowing money (many people do), keep an eye on interest rates. Do you have ready access to a low-interest loan, such as a home equity line of credit? Borrowing against your home's equity usually provides the best interest rates because the lender's loan is secured by your home and land.

Are current interest rates at a historically low point that makes it attractive to remortgage your home to include extra cash for your addition? If so, then it may be a good time to go ahead with that major project But during times of historically high interest rates, it may be better to choose a smaller addition that is more affordable.

Article Source

Top 10 Tips For Engineering Students

The onset of another academic year heralds a fresh intake of bright young engineers preparing to tackle the rigours of an undergraduate or postgraduate engineering degree. Of course, you're already an accomplished student, so we won't bore you with finger-wagging lectures about burning the candle at both ends. Instead, we'd like to offer you ten practical tips for engineering students to maximize your educational experience and heighten your engineering professional instincts.

10) Develop good habits

Attending lectures regularly is imperative if you're to avoid falling behind. If you can't attend, for whatever reason, move mountains to make up the work immediately because there's a huge volume of information that engineers need to digest and keep abreast of. It's also a good idea to do some reading ahead before a lecture, and to review lecture notes soon after, to consolidate all these new theories and data.

9) Do your homework

If you're an able student who's always cruised through your studies, picking up As and Bs for fun, then Higher Education might be a rude awakening. You're the sole custodian of your education, which means putting in the hard yards, completing assignments on time and sweating over the books – to ace the tests and nurture great working habits for the real world.

8) Enlist a second opinion

It's not unusual for practicing engineers to encounter problems that leave them stumped and in need of a second opinion. If it's good enough for them, it's good enough for you. So enlist the brain power of professors, graduate assistants, tutors and high flying peers to talk over any quandaries. The more you access them, the more they will willingly respond and assist.

7) Know thy calculator

Your new best friend is going to be your steadfast ally for the foreseeable future. Brush up on all its advanced features and idiosyncrasies to save you precious time and stress in any pressure situations.

6) Learn CAD and code

You may well be a coding and CAD ninja. However, if it all seems double Dutch to you it's probably worth learning some basics. The ability to sketch 3D models is a pre-requisite nowadays and makes you a valuable asset to future employers. Meanwhile, code can be a powerful tool to crunch numbers and make equation heavy assignments a formality.

5) Ask questions

If you're finding a topic difficult to follow, chances are a good few of your colleagues are struggling too. Break the mould and be brave. If you don't clarify things at this stage, when you can gain a more detailed explanation, it will be twice as hard to understand when you're on your own. Your fellow students, and your grades, will thank you for it in the long run.

4) Form a study group

A practicing engineer wouldn't think twice about collaborating with a team of colleagues to solve a problem. So why wouldn't you team up with your classmates to chat through solutions and generally spur each other on? For the very best results it's worth mixing with the high-flying first class students to reach the peak of your academic powers.

3) Apply for an internship

At the end of the day, all your laborious study is geared up for one thing only; to get you a job when you graduate. Gain some invaluable experience, and a foot in the door, by applying for an internship. Not only will it look great on your CV but it's also a gilt-edged opportunity to practice academic theories in a real-time environment.

2) Believe in yourself

Discount that naysaying little voice in your head that suggests you're a fraud. If you progress through your first year of engineering studies, then you almost certainly have what it takes to become a fully fledged engineer. Through hard work and application you can silence those nagging fears and achieve your true potential.

1) Enjoy it!

That brings us nicely to our final tip. Enjoy it! The following years of study, and social excitement, are certain to be among the best of your life. They'll also be some of the quickest. So make the most of your freedom and sponge up every new experience. Good luck!

Article Source

Steel Beams-The Backbone Of Modern Construction

Steel beams are horizontal or diagonal structural members that are designed to carry transverse loading across a span onto vertical columns at each end.

They provide support to floors, roofs, and walls in buildings as well as serve as main spanning members in bridges.

Types Of Steel Beams

Common types of steel beams consist of standard “I-beam” shapes as well as unique configurations including:

I-Beams: Most widely used “W-shape” beams with optimal balance of strength, cost, and construction ease. Come in varying depths and flange widths.

Wide Flange: Similar to I-beam but with thicker flanges for increased strength in bending and compression. Used in long spans.

Plate Girders: Fabricated I-beams built up from separate steel plates. This allows custom heights and proportions for longer spans or heavier loads.

Box Beams: Hollow structural sections shaped like rectangles or squares. Provide excellent torque resistance. Used as bridge beams.

Applications Of Steel Beams

Steel beams serve numerous structural purposes:

Floor Framing: Primary floor supports over interior spaces, designed for human live loads.

Roof Framing: Span longer distances to cover open plan spaces while still allowing drainage slopes.

Long Span Bridges: Plate girder and box beam configurations.

Crane Runways: Carry dedicated heavy live loading from overhead crane operation.

Design Considerations

Engineers evaluate:

Loading Magnitudes: Beam depth governs required capacity

Deflection Limits: Prevent excessive bending

Shear Resistance: Throat thickness provides shear strength

Connection Detailing: Welded or bolted to structure

Best Steel Types For Beams; Common grades like ASTM A36, A572, A992, A913 offer excellent strength-to-cost rations.

Key factors:

• Yield and Tensile Strength
• Formability and Weldability
• Availability for Fab and Construction
• Constructing Steel Beams

Typical sequence includes:

• Fabricate beam based on architectural/structural drawings
• Deliver beams to site and temporarily brace

• Make end connections to columns using welding or bolting
• Install supplemental braces, plates. Apply fireproofing.

Article Source

Guide to Planning your Detached, Newly Constructed, Residential Accessory Dwelling Unit

This guide is intended to assist you in determining the feasibility of adding an ADU to your property and will help answer your questions of “How large of an ADU can I add?”, “Where on my property will an ADU fit?”, and many more. The intent with this guide is to be a self-service guide; however, a design professional can be consulted during this early stage as well to help you through this process. This guide poses questions to be considered and checked with your local jurisdictional requirements. You should contact your local building, planning, and environmental health departments to receive their individual requirements.

Each jurisdiction will vary in requirements and may have additional planning requirements to consider beyond this guide. It is important to review the date of your local jurisdiction’s ADU zoning requirements. Many jurisdictions have not modified their requirements to meet the State’s requirements that became effective January 1, 2020. If the local jurisdiction’s requirements are not compliant with the State requirements, then the State requirements supersede.

You can find information about your local jurisdiction by searching online for the name of your County, City, or Town and “Planning Department”.

Step 1 – Determine area allowed for ADU

Here you will want to mark out the minimum setbacks and minimum separations between the ADU and other structures on your property (minimum separations and setbacks can be determined by speaking with your local jurisdiction, rear and side setback minimums are 4’ per State law, however local jurisdictions may reduce this minimum). Once these are marked out, you can measure the allowable footprint of the ADU. This will allow you to calculate the size limitations of the ADU for the property.

Other features to mark out will include the sewer line or septic tanks and leach-field, water line (and well if applicable), utility lines, easements, driveway(s), parking areas, etc and their respective setbacks.

Items to note:

 Fire separation systems will be required if certain setbacks are not maintained. These will increase construction costs and will drive certain design features. If possible, maintaining 5’ between the ADU and property lines will help reduce costs.

Property boundary surveys may be required when constructing close to property lines. You will need to check with your local jurisdictional requirements to determine if a survey is required.

Completing this step will also create the foundation for the site plan, which will be required as part of the submittal package.

Step 2 – Determine jurisdictional planning requirements

What is the maximum height allowed by your jurisdiction? State law requires the maximum height to be at least 16’.

Is your lot in a flood zone? Can the floor of the ADU be located above the minimum flood elevation requirements and still meet the maximum height requirements?

Must the ADU be of similar roof lines, shapes, material finishes, etc as the primary residence? Is a ministerial permit required?

Can parking be accommodated? 1 off-street parking space may be required per ADU. Consider the path of travel from parking areas to the ADU (can your standard of privacy be maintained). What is the distance of this path of travel? Additional requirements may apply.

What is the distance to the nearest fire hydrant?

What dwellings already exist on your property? State law allows for 1 primary residence, 1 ADU, and 1 junior ADU.

Step 3 – Determine environmental factors

Will the placement of your ADU require the removal of trees? In some jurisdictions, the removal of trees may be limited per jurisdictional requirements.

If your property is on a septic system many jurisdictions will require a separate septic tank be installed for the ADU, and may allow the existing leach-field to be utilized and expanded. Is there space for the expansion of the existing leach-field? Or will a new leach-field for the ADU be required, and is there room on the property for this?

Depending on the location of the ADU in relation to property lines and other structures, additional drainage features may be required. For example, the ground is typically graded away from foundations for the first 6’. If the property line and/or other structures impede this 6’, other measures will be required.

Item to note:

 In certain circumstances, buildings may be placed over waterlines and wastewater lines. Buildings may not be placed over septic tanks or active leach-fields.

Step 4 – Determine the maximum footprint of your desired ADU

What size ADU would you prefer? This number must be equal to or less than the size determined in step 1. A few key numbers to remember:

• 1200 sqft of conditioned space is the maximum allowed by State law
• 150 sqft of conditioned space is the minimum size required
• If you are less than 750 sqft of conditioned space, no impact fees will be assessed.
• Local jurisdictions must allow up to 800 sqft to be constructed regardless of lot coverage requirements. Above 800 sqft may be subject to limitations of lot size, lot coverage, lot coverage specifically around the ADU, bedroom counts, etc.
• This 800 sqft is not defined to one type of measurement. Some jurisdictions will allow up to 800 sqft of conditioned, while others will allow up to 800 sqft of footprint, and others yet will count some covered porches, depending on configuration. The way the local jurisdiction measures this must be determined during this step if lot coverage may be an issue.
• Does your jurisdiction limit the size of covered porches, attached carports/garages, decks?
• 1 bedroom units may be limited to 850 sqft, 2 bedroom units may be limited to 1000 sqft.

Step 5 – Determine utility requirements

In step 1, you marked out existing utilities. How will these utilities be affected by the ADU? Will wastewater from the ADU be able to drain properly to the septic system or sewer line?

What is the flow of your fresh water supply? Is this sufficient to provide water to an additional unit? Or will a larger line be required? If your property is supplied by a well, does the well produce enough water flow for another unit?

What is the distance of new water line, sewer line, electrical line, gas line, etc required to be installed? What are the lead times and requirements posed by your local utility companies to make these changes?

Step 6 – Determine if grading will be required

Is the lot relatively flat? ADUs can extend 50’ or more in one direction, or as little as 10’ or less. ADU placement with the slope of the lot can help reduce grading, but may not entirely negate it. Depending on your jurisdiction, a grading permit may be required. You can roughly estimate the amount of material needed to be graded by multiplying the average depth of grading by the total footprint of the unit. If this number is close to, or exceeds the local jurisdiction requirements, a grading plan may be required.

Step 7 – Repeat Steps 4-6 (if required)

If you find the costs associated with utilities and/or grading are becoming too high, you may want to consider reducing the size or reconfiguring the shape of your ADU by repeating steps 4-6.

Step 8 – Begin the design phase of your ADU

You are finally ready to begin designing your ADU. This can take place in many forms. You may be ready to sit down with a design professional and work through various layouts, or you may want to sketch some ideas out yourself. Either way, you will now know your building limitations (height, allowable conditioned space, allowable footprint, and allowable size of covered porches and attached garages, etc.) Here at Jackson & Sands Engineering, Inc., we have a number of pre developed ADUs that may fit all your design needs. Utilizing a pre developed design can help save you both time and thousands of dollars in design costs.

Article Source

Footing Thickness and Factors Affecting Thickness

There are many factors to consider when determining the optimal foundation thickness and the minimum foundation thickness. Foundation width and thickness are interconnected, and they depend on the load applied to the foundation.

Factors Affecting Footing Thickness

• Soil type

The type of soil on the project site will have a big impact on the required footing thickness. Soil types can be classified as sandy, clayey, or gravelly. Each soil type has different engineering properties that need to be considered.

Main the allowable bearing capacity is connected with the soil type. The condition of the soil leads to different bearing capacities. Lesser the bearing capacity of the soil higher the bending moment of the footing. It causes to increase in the thickness of the footing.

• Exposure Condition

The condition of the ground or the environment in which the structure is built is a very important factor in determining foundation thinness.

It is connected with the strength and durability of the foundation. Depending on the exposure condition select the cover to the reinforcement with affected the thickness of the footing. Further, we used to select the grade of the concrete also based on the exposure condition in modern design. Therefore, there is a direct relationship between the exposure condition with the foundation thickness.

• Applied Loads

The maximum bending moment and the share force on the footing are the main results of the column load on the footing. Depending on the bending and shear, the thickness of the footing will vary.

How to Determine Minimum Thickness of Footing

There are no special norms for the minimum thickness of foundation other than the general design practices to follow as per the relevant code of practices.

Those factors could be the main concerns for the footing design and determining the minimum foundation thickness.

• Bending and Shear Requirements

Footing shall be able to withstand the bending and shear forces (vertical line shear and punching shear) induced due to the applied loads. Accordingly, we can determine the minimum thickness for the foundation. We can always increase thickness, but minimum thickness shall meet these design requirements.

In addition, other design requirements such as an increase in the cover due to adverse exposure conditions, etc. also will directly affect the foundation thickness.

Generally, the minimum footing thickness would be considered as 200mm for any type of footing such as pad footing, wall foundations, strip footings, etc...

Article Source

Column Failure And Its Different Types

Column is a very important structural component that boosts the structural integrity . It transfers the load from the structure to the ground through foundation. The entire stability of structure lies on how perfect the column is designed and constructed. The failure of the reinforced concrete column leads to the failure of the whole structure. So It is very important to identify the column failure in advance if any and take necessary remedial steps to eradicate them. If the column failures are not checked at regular intervals this may lead to collapse of the entire structure. Failure in the column occurs for many reasons.

Column Failure Reason

• Excessive loading: When the applied load exceeds the design capacity of the column, it can cause buckling, crushing, or shear failure.
• Material defects: Flaws in the material or fabrication of the column, such as cracks, corrosion, or low quality concrete, can reduce its strength and durability.
• Environmental effects: Exposure to harsh weather conditions, such as moisture, temperature changes, or earthquakes, can damage the column and its connections.
• Design errors: Mistakes in the design or construction of the column, such as inadequate reinforcement, insufficient cross-section, or improper alignment, can lead to failure.

Other  than these common causes there are few specific structural reasons that tend the column member to fail.

Column Failure Modes

Column failure modes are the ways in which a column can lose its ability to support a load.

Columns are structural elements that are designed to resist compression forces, but they can also be subjected to bending, shear, and torsion. Depending on the material, geometry, and loading conditions of a column, different failure modes can occur.

Some common column failure modes are:

• Buckling: This occurs when a column becomes unstable under compressive load and bends out of its original shape. Buckling can be prevented by increasing the stiffness or slenderness ratio of the column, or by providing lateral support.
• Crushing: This occurs when a column reaches its ultimate compressive strength and collapses. Crushing can be prevented by increasing the strength or cross-sectional area of the column, or by reducing the applied load.
• Shear failure: This occurs when a column fails due to shear stress, which is perpendicular to the longitudinal axis of the column. Shear failure can be prevented by increasing the shear strength or shear reinforcement of the column, or by reducing the transverse load.
• Torsional failure: This occurs when a column fails due to torsional stress, which is twisting around the longitudinal axis of the column. Torsional failure can be prevented by increasing the torsional strength or torsional reinforcement of the column, or by reducing the twisting load.

Column failure modes are important to understand for engineers and architects who design and construct buildings and structures. By knowing the possible failure modes of a column, they can choose the appropriate material, geometry, and loading conditions to ensure safety and stability.

Column Failure Types

Columns are the vertical load carrying members that take axial compressive loads from the superstructure.

Column failures are one of the most common and dangerous structural problems that can occur in buildings. It  may be due to many reasons.

One main cause for failure is slenderness ratio, which is the ratio of its effective length to its least lateral dimension. Slender columns tend to fail by buckling, while short columns tend to fail by crushing.

Based on slenderness ratio there are three types of failures majorly observed in the rcc columns, they are ,

• Pure compression failure
• Buckling failure
• Shear failure

Compression Failure

This type of failure  usually occurs due to the development of the compressive stresses greater than the allowable stresses.  When the columns are loaded axially the steel and the concrete in the column experience some stresses. When the load on the column is further increased and reaches greater amounts  than the cross sectional area of the column then the steel and concrete will reach the yielding stress leading to the failure without later deformation. To avoid this type of failure, overloading of the column to be avoided, cross-sectional area column provided depending on the loading conditions, and finally the stresses developed due compressive strength in  the column should be less than that designed for the column.

Buckling Failure

 This type is usually observed in long or slender columns. For the slender or long  columns the least lateral dimension is greater than 12 , and has very less load carrying capacity.

When the load is applied on such columns , the column becomes unstable and  may fail showing a sideways bend called column buckling. This may occur even for very small loads .This means that concrete and steel in the column reaches the yielding stress even for application of small loads showing the failure.

Column buckling can be avoided by not constructing the long columns whose slenderness ratio is greater than 30. For designing the slender columns special care is to be taken such that the column can resist itself from buckling. If possible it is better to increase the least width of the column to avoid slenderness.

Shear Failure

This type of failure occurs when the shear force developed in the column is more than the shear capacity of the column. The shear load on the column develops sliding failure which in the form of the shear cracks developed in the column along the plane parallel or diagonal to the direction of application of the force.

To resist the shear force developed in the RCC column we have to provide shear reinforcement or tie bars, if they are not adequate to take the shear force then the column may fail. This type of failure can be avoided by designing the column with required tie rebars to confine the main bars.

Other Column Failure Modes

In accordance with the above modes of failures some other types of failures observed in column are as follows

Failure Due To Lack Of Confinement Reinforcement

Vertical element subjected to cyclic loadings subjected to failure of this nature.

Failure causes mainly due to the lack of links in the area where there are higher shear forces.

In structural elements such as beams and columns, higher stresses are generated near the connections. Lack of links in these areas causes structural failures when cyclic loadings are applied.

Torsional Failures

There is a probability of columns subjected to torsional moments.

Usually, columns are designed for axial, bending, and shear forces. However, due to the irregularities in the structure, the torsional behavior of the column can be observed.

Columns are torsionally rigid when they are compared with the beam as they have reinforcement around the section and links are provided at closer spacings.

However, if the torque exceeds the limiting values, columns could fail in torsion.

Failure Due To The Errors In The Construction

There may be many errors that could happen in construction and they also can be categorized under types of column failure. Employing qualified engineers to the project and close supervision of construction work will minimize these types of column failure.

• Mistakenly reduce the bar diameter
• Construct an incorrect column in the location
• Changes in the grade of concrete
• Lack of strength in the concrete due to the failure of the concrete supplier

Prevention And Repair Of Column Failures

Column failures can be prevented by following good design and construction practices, such as:

• Choosing appropriate materials and specifications for the column and its connections
• Providing adequate reinforcement and cross-section for the column
• Considering the effects of loading and environmental conditions on the column
• Performing regular inspection and maintenance of the column

Repair Methods

If a column failure occurs, it should be repaired as soon as possible to restore its functionality and safety. The repair method depends on the type and extent of damage, but some common techniques include:

• Replacing or strengthening the damaged column or its connections
•  Applying external jackets or wraps around the column
• Injecting epoxy or grout into the cracks or voids in the column
•  Adding supplementary supports or braces to the column

Article Source
